DFC365 FX Digital Camera from Leica

Speed and image quality are the key factors for successful documentation of live cells and rapidly fading fluorescence specimens.

The new Leica DFC365 FX 1.4 mp monochrome digital camera combines brilliant imaging with very high temporal resolution (up to 21 fps full frame). With state-of-the-art CCD technology, the camera offers a dual imaging mode with NIR (near infra red) capability for enhanced quantum efficiency between 700-1000 nm wavelength.

The high-sensitivity sensor and active-regulated Peltier cooling provide an excellent signal to noise ratio - making this camera ideal for demanding fluorescence applications such as Structured Illumination, TIRF and FRET experiments.

Advantages:

Extremely high frame rates

Extremely high frame rates: with overlapping mode, the 2/3" Progressive Scan CCD sensor reads out imaging data while the next exposure is taken.

Optional NIR (near infra red) mode

This optional imaging mode provides significant enhanced quantum efficiency and makes this camera ideally suited to monitor CY5 and Cy7 fluorescent dyes.

Ultra-fast read out of definable areas

Partial scan mode allows the ultra-fast read out of definable areas at full resolution. Can be combined with overlapping mode and binning.

Brilliant image quality

In addition to high-speed image acquisition with either 40 or 20 MHz, the additional clocking rate of 1.6 MHz enables superb fluorescence documentation.

Fast and reliable data transfer

With FireWire IEEE1394 b interface for fast and reliable data transfer.
