The Blood Bank Refrigerator B701 has a storage capacity of 645 L | 22.78 cu ft.
- Set Temperature: +4 °C
- Climate class (ambient temperature range): +10 °C to +43 °C
- Alarm limits: +2.5 °C | +5.5 °C
- External dimensions (H × W × D): 1988 × 992 × 1039 mm | 78.27 × 39.06 × 40.91 inches
- Refrigerant Type: Natural R600a
Image Credit: B Medical Systems
Download the Brochure for More Information
Description
Reliability
- A controlled air conditioning system ensures homogeneous and steady temperature distribution.
- Fast temperature recovery, even with numerous door openings.
- The safety thermostat prevents temperatures below freezing.
- Extended autonomy in the event of power breakdown.
- An audiovisual alarm system that can be remotely transmitted via email or SMS.
- °B Connected universal software for remote monitoring, reporting (in accordance with FDA 21 CFR Part 11), and long-term archiving.
Image Credit: B Medical Systems
Efficiency
- Natural refrigerant with great cooling efficiency, compliant with US SNAP and EU F-Gas laws.
- High-performance compressor for improved energy efficiency.
- High-quality stainless steel cabinets with antibacterial treatment are injected with thin polyurethane foam, which provides good thermal insulation and storage capacity.
- Sealed gaskets and a 5-layered glass window reduce cold air loss.
- LED interior lighting that operates automatically to save energy.
Image Credit: B Medical Systems
Convenience
- Antibacterial coating for easy hygiene control.
- Easy access to parameters on a 7” touchscreen with temperature display.
- Easy access to the lower drawers.
- Low heat emission.
- Low-noise appliance.
- Modular interior equipment.
- Organic glass window for better visibility of the refrigerated content.
- Password protected/NFC card-based door locking mechanism.
- USB port and SD card slot for easy export of data.
Image Credit: B Medical Systems
Download the Brochure for More Information
Technical specifications
Source: B Medical Systems
| . |
. |
| Gross volume |
792 L | 27.97 cu ft |
| Storage Capacity |
645 L | 22.78 cu ft |
| Blood bag capacity (450 ml) |
450 |
| Blood bag capacity (350 ml) |
625 |
| Set Temperature |
+4 °C |
| Alarm limits |
+2.5 °C | +5.5 °C |
Climate class
(ambient temperature range) |
+10 °C to +43 °C |
| Certifications |
cCSAus | EU MDR Class IIa | ISO 14644-1 | Class 4 | SCoPE | US FDA Class II |
| Cooling technology |
Forced air cooling system |
| External dimensions (H × W × D) |
1988 × 992 × 1039 mm | 78.27× 39.06 × 40.91 in |
| Internal dimensions (H × W × D) |
1173 × 740 × 743 mm | 46.18 × 29.13 × 29.25 in |
| Net weight |
251 kg | 553.36 lb |
| Frequency |
50-60 Hz |
| Supply voltage |
220-240 V |
| Energy consumption |
1.5 kWh/24 h (50 Hz) | 1.6 kWh/24 h (60 Hz) |
| Noise level |
50 dB (50 Hz) | 51 dB (60 Hz) |
| Refrigerant Type |
Natural R600a |
| Heat emission |
36 Kcal/h |
| Materials |
Stainless steel |
| Display |
7" touchscreen screen |
| Remote monitoring |
°B Connected software |
| Hold over time |
2.7 h (+4 °C to +10 °C) |
| Defrosting technique |
Natural |
| Access control |
Password or badge |
| Data export |
SD card | USB port |
| Product Type |
Blood Bank Refrigerator |
