The capacity of the Plasma Storage Freezer F901 is 768 L | 27.12 cubic feet.
- Set Temperature: –41 °C
- Climate class (ambient temperature range): +10 °C to +43 °C
- Alarm limits: –32 °C | –46 °C
- External dimensions (H × W × D): 1988 × 1139 × 1039 mm | 78.27 × 44.84 × 40.91 inches
- Refrigerant Type: Natural R290
Image Credit: B Medical Systems
Download the Brochure for More Information
Description
Accurate temperature control and 24/7 monitoring
- °B Connected universal software for remote monitoring, reporting (in compliance with FDA 21 CFR Part 11), and long-term archiving.
- Audio-visual alarm system with remote transmission via SMS or email.
- Automatic switch-off of the evaporator fans at each door opening to reduce heat transfer.
- Controlled air cooling system for uniform and stable temperature distribution.
- Extended autonomy in case of power failure.
- Fast temperature recovery even in the case of frequent door openings.
- Smart automatic defrosting technology enables a stable temperature during the defrost cycle.
Image Credit: B Medical Systems
Energy-efficient and eco-friendly performance
- Frost prevention reduces pressure on the compressor.
- High cooling efficiency through natural refrigerants in conformity with US SNAP and EU F-Gas regulations.
- High-quality stainless steel cabinets with antibacterial coating and injected with thin polyurethane foam, providing high thermal insulation and storage capacity.
- Insulated inner doors, sealed gaskets, and enhanced frame for minimized cold air loss and heat conduction.
Image Credit: B Medical Systems
Ergonomic design
- Easy access to the lower drawers.
- High-quality stainless steel and other materials for an extended life span.
- 7” touchscreen with temperature display easily accessible on the door handle.
- Minimal ice formation allows for easy deicing.
- Modular interior equipment
- Password protected/NFC card-based door locking mechanism.
- Set point of -41 °C
- USB port and SD card slot for easy export of data.
Image Credit: B Medical Systems
Download the Brochure for More Information
Technical specifications
Source: B Medical Systems
| . |
. |
| Gross volume |
949 L | 33.51 cu ft |
| Storage Capacity |
768 L | 27.12 cu ft |
| Blood bag capacity (350 ml) |
690 |
| Set Temperature |
-41 °C |
| Temperature range |
-41 °C to -32 °C |
| Alarm limits |
– 32 °C | – 46 °C |
Climate class
(ambient temperature range) |
+10 °C to +43 °C |
| Certifications |
cCSAus | EU MDR Class IIa | ISO 14644-1 | Class 4 | SCoPE | US FDA Class II |
| Cooling technology |
Forced air cooling system |
| External dimensions (H × W × D) |
1988 × 1139 × 1039 mm | 78.27 × 44.84 × 40.91 in |
| Internal dimensions (H × W × D) |
1173 × 887 × 738 mm | 46.18 × 34.92 × 29.05 in |
| Net weight |
346 kg | 762.80 lb |
| Frequency |
50 Hz |
| Supply voltage |
230 V |
| Energy consumption |
6.8 kWh/24 h |
| Refrigerant Type |
Natural R290 |
| Heat emission |
244 Kcal/h |
| Materials |
Stainless steel |
| Display |
7" touchscreen screen |
| Remote monitoring |
°B Connected software |
| Hold over time |
5.7 h (-41 °C to -10 °C) |
| Defrosting technique |
Automatic (hot gas) |
| Access control |
Password or badge |
| Data export |
SD card | USB port |
| Product Type |
Plasma Storage Freezer |
